Large Single Row Cross Roller Slewing Bearing for Wind Power

Large Single row Cross Roller Slewing Bearing for Wind Power

Luoyang Xinqianglian Slewing Bearing Co., Ltd.  ( Hereinafter referred to as the LYXQL) founded in 2003, is located in the ancient capital of nine dynasties Luoyang in Henan province. LYXQL is a national key high-tech enterprises and become a GEM listing company successfully on July 13,2020 (stock code "300850").

细节图1

LYXQL Large Single row Cross Roller Slewing Bearing is an important part of Wind Power machine .Its work safety, reliability requirements are very high. Large Cross Roller Slewing Bearing is characterized by low speed and high load. LYXQL Large Single row Cross Roller Slewing Bearing for Wind Power is composed of two seat rings, with compact structure, light weight, high manufacturing accuracy, small assembly clearance, and high requirements for installation accuracy. The rollers are arranged in a 1:1 cross.

LYXQL Single row Large Cross Roller Slewing Bearing for Wind Power have a series of advantages such as small size, high rotation accuracy, strong resistance to deformation, large carrying capacity and flexible structural design.

LYXQL Single row Large Cross Roller Slewing Bearing can support combinations of large radial force, medium axial force and tilting moment with small or zero clearance. Main applications of this kind of bearings are hoisting and mechanical handling and general mechanical engineering etc.The product outer dimension can be from 500mm to 25000mm.

细节图2

LYXQL Single row Large Cross Roller Slewing Bearing for Wind Power------Technical Data:
1. Material: 42CrMo, 50Mn
2. Precision: P0. P6. P5.
3. Outside diameter: 500~25000mm
4. Cage/retainer: Nylon or aluminum
5. Gear type: non-geared, internal gear and external gear, gear hardened

LYXQL Single row Cross Roller Slewing Bearing---Teeth Structure
Slewing ring bearings with no gear
Slewing ring bearings with external gear
Slewing ring bearings with internal gear

LYXQL Single row Cross Roller Slewing Bearing for Wind Power----Surface treatment:

1: black surface treatment

2: Surface sandblasting and painting

3: Surface chrome plating

4: Surface spray zinc treatment

5: Surface phosphating treatment

6: Dacromet treatment

细节图3

LYXQL Cross Roller Slewing Bearing for Wind Power------Packaging Details:
Step 1: Covered with the anti-rust oil
Step 2: wrapped with the plastic film;
Step 3: Packed with Kraft paper and professional belts;
Step 4: Put into wooden box to avoid the rust or the moist;
Remark: Normally, plastic film+ Kraft +belt+ wooden box, but customized packing available,
